4-channel high-end UFS product
Support multiple queues (transfer rate)
Support high-reliability features including RAID protection
Sequential read/write up to 1,650/1,000 MB/s
4K random read/write up to 160K/125K IOPS
Faster page loading and more responsive operations
Support three power consumption levels: LV1, LV2, LV3
Power consumption of standalone ICCQ as low as 160µA in LV3 mode
Reduce device heating and extend battery life
Support hardware decoding, software decoding, WB SLC performance, RAID, and more
Multiple reliability algorithms and features
Ensure long-term, stable device operation
| Form Factor | UFS 3.1 |
| Capacity | 128GB |
| Dimensions | 11.5mm*13.0mm*1.0mm |
| JEDEC Standard | JESD220E |
| Temperature |
Operating: 0°C to 70°C Storage: -40°C to 85°C |
| Humidity | 5% to 95% |
| Supply Voltage |
VCCQ：1.2V VCC：2.5V |
