Dynamic mode strategy significantly boosts device performance
Support high-reliability partitions including Boot partition, RPMB, and Enhanced area
Support extended BOL data retention — 10 years at 43°C
Sequential read up to 330 MB/s and sequential write up to 290 MB/s
4K random read up to 33K IOPS and 4K random write up to 30K IOPS
ECC features an LDPC engine supporting hard/soft decoding
Read reliability features include Read Refresh, Reclaim, and Retry
NAND media Assistant Read feature
SPOR abnormal power-off protection and bad block marking
Up to 16 driver strength settings
Better compatibility across various devices and interface standards
Stable data transmission assured
The next-gen eMMC 5.1 has undergone industry-leading unit testing and ATE 3-temperature CHAR characterization testing and reliability testing equipment and capabilities to ensure reliable product quality
|
Capacity |
64GB |
128GB |
256GB |
|
Dimensions |
BGA 153Ball, 11.5mm*13.0mm*1.0mm |
||
|
Bus Interface |
eMMC 5.1 Interface |
||
|
eMMC Standard |
JESD84-B51A |
||
|
Temperature |
Operating: -25°C to 85°C |
||
|
Supply Voltage |
VCCQ: 1.8V |
||
